Fiber marking machine
Feature:
-
It adopts full aluminum workbench plate featured with high bearing capability, solid and durableness; section integrated elevating frame is solid and stable, with strong resistance to shock;with strong commonality, it is suitable for all kinds of industries; equipped with scale plate ,its marking and location are precise and easy; the large working bench is capable to realize the continuous marking within the large scope. The fiber laser marking system adopts the integrated design, with compact size, low consumption, long life-span, high efficiency, free from maintenance, with superior laser beam, and precise light sopt, it is no need to consumable items. The scanning galvanometer is imported with original packaging , with good seal, capable to prevent dust and water, small volume, compact and solid, and the performance is superior and power is excellent. With German marking machine software and controlled USB interface, the transmission is swift, stable, with digital transmission function and the software operation is easy and of strong function.
Desktop fiber marking machine
| Model no.. |
CL GQ-10W |
CL GQ-20W |
| Output power: |
10W(continuation or pulse) |
20W(continuation or pulse) |
| Wavelength: |
1064nm |
1064nm |
| Power adjustment range: |
10-100% |
10-100% |
| Repeat frequency: |
20-100KHZ |
20-100KHZ |
| Min. character size: |
0.15mm |
0.15mm |
| Repeat frequency: |
±0.001mm |
±0.001mm |
| Max.Linear speed: |
3000-5000mm/s |
7000mm/s |
| Format |
PCX、DXF、BMP file format |
PCX、DXF、BMP file format |
| Marking range(MM) |
110mm×110mm,140mm*140mm, 175x175mm |
110mm×110mm,140mm*140mm, 175x175mm |
| Power supply: |
220V±10%/50Hz/4A |
220V±10%/50Hz/4A |
| Cooling: |
air cooling |
air cooling |
| Format |
USB |
USB |
| Laser module life: |
＞100000hours |
＞100000hours |
Portable fiber marking machine
| Model no.. |
CL GQ-10W |
CL GQ-20W |
| Output power: |
10W(continuation or pulse) |
20W(continuation or pulse) |
| Wavelength: |
1064nm |
1064nm |
| Power adjustment range: |
10-100% |
10-100% |
| Repeat frequency: |
20-100KHZ |
20-100KHZ |
| Min. character size: |
0.15mm |
0.15mm |
| Repeat frequency: |
±0.001mm |
±0.001mm |
| Max.Linear speed: |
3000-5000mm/s |
7000mm/s |
| Format |
PCX、DXF、BMP file format |
PCX、DXF、BMP file format |
| Marking range(MM) |
110mm×110mm,140mm*140mm, 175x175mm |
110mm×110mm,140mm*140mm, 175x175mm |
| Power supply: |
220V±10%/50Hz/4A |
220V±10%/50Hz/4A |
| Cooling: |
air cooling |
air cooling |
| Format |
USB |
USB |
| Laser module life: |
＞100000hours |
＞100000hours |
Applicable materials:
It is capable of curving the metal material and partial non-metal materials, especially suitable for some fields required more precise and higher smoothness.
Application Industial:
It is widely used in the electronics separation components, integrated circuit ,electrical engineering circuit , mobile communication, hardware, tools, kitchen wares, tool fittings ,precise apparatus, eyeglasses and clock, computer keyboard, jewelry accessories, plastic buttons, water heating fittings, sanitary ware, PVC pipelines, medical apparatus and packing container, etc.
Sample Photos:
Widely apply to different kinds of consumer commodities, food beverage packaging, medicine packing, architecture, ceramic, costume and accessories, leather and wool, gift and crafts, nameplates, jeans, furniture ,etc
